ASUS FX502 packs the latest 6th gen Intel® processor, Windows 10, and NVIDIA® GeForce® GTX graphics in a compact and lightweight design. ASUS FX502 enables users to work efficiently from anywhere.
EXCELLENT PERFORMANCE
ASUS FX502 delivers excellent performance thanks to the 6th-generation Intel® Core™ i7 core processor combined with a discrete NVIDIA® GeForce® GTX 1060 graphics with full Microsoft® DirectX® 12 support. The hardware gives you efficient and powerful performance along with stylish and light-weight design for more productive multitasking.
GAMING ON-THE-GO
With a profile measuring just 23.5 mm and tipping the scales at a lightweight 2.2 kg, ASUS FX502 has an ultra-portable design that fits snugly in a messenger bag or backpack. Whether you’re going out for a meeting or kicking back at a café you can game just about anywhere!
BREATHTAKING VISUALS BEAUTIFUL WIDE-VIEW PANEL
ASUS FX502 gives you superior images with lifelike colors thanks to 100% sRGB color gamut. It utilizes a 15-inch panel with super-fast wide-view panel to give you wide 178° viewing angles so there’s no color shift even when you’re viewing it from extreme positions.
INTELLIGENT THERMAL DESIGN
The Hyper Cool Duo-Copper cooling system uses heat pipes and a dual fan system to cool the CPU and GPU independently. This design maximizes cooling efficiency to give ASUS FX502 the stability required at any need.
UP TO 24 GB OF DDR4
ASUS FX502 is fitted with up to 24GB of DDR4 RAM. Perfect in speed, capacity and low power consumption that deliver moderate performance any time.
TACTILE KEYBOARD
ASUS FX502 has a specially-designed chiclet keyboard with red-backlit scissor-switch keys that offer you 1.6mm of travel distance for tactile keystrokes. It also features highlighted WASD keys so you know where your hands need to be.
FILTER OUT ALL AMBIENT NOISE
The array microphones are designed to filter out ambient noise, which means that even if you’re having a con-call in some loud environment, your voice is still clearly heard.
AUDIO BY ICEPOWER®
With a slick design, the built-in speakers are positioned so that you can make the most out of your audible experience.
FX502VM-DM092T (PHP 69,995)
| Part No | 90NB0DR5-M01620 |
| Model Name | FX502VM-DM092T |
| EAN Code | |
| UPC Code | |
| LCD Cover Color & Decoration | Black–Aluminum |
| Top Case Color & Decoration | Black–Plastic |
| On board processor | Intel® Core™ i5-6300HQ Processor 2.3 GHz (6M Cache, up to 3.2 GHz) |
| Operating System | Windows 10 (64bit) |
| Office | Includes 1 month Trial for New Microsoft Office 365 Customers |
| Chipset | Mobile Intel® HM170 Express Chipsets |
| Memory Slot | 1x |
| On board memory | DDR4 8GB |
| Memory Max. | 24G |
| Total System Memory | DDR4 8GB |
| Storage | SATA 1TB 7200RPM 2.5′ HDD |
| EMMC/ISSD | N/A |
| Display | 15.6’//LED Back-lit//Ultra Slim 200nits//FHD 1920×1080 16:9//AG//NTSC:45%//WVFILM 140 degrees |
| External video display modes | HDMI 1.4 |
| Discrete/Share | Discrete |
| Video Graphics | NVIDIA GeForce GTX1060 (N17E-G1) |
| IGPU | N/A |
| Video memory | GDDR5 3GB |
| Video Camera | HD web camera |
| FingerPrint | N/A |
| On board Wireless | N/A |
| Wireless(Module) | 802.11ac+Bluetooth 4.1 (Dual band) 2*2 |
| LAN | 10/100/1000 Mbps |
| Card Reader | Sepc: SD、MMC |
| USB Port | 3x USB 3.0 1x USB3.1 Type C (gen 2) |
| Interface | 1x Headphone-out & Audio-in Combo Jack 1x RJ45 LAN Jack for LAN insert 1x HDMI 1x mini Display Port 1x USB3.1-Type C(Gen2) with Thunderbolt |
| Audio | Built-in speaker Built-in array microphone Audio by ICEpower® Sonic Master |
| Weight (Kg) | 2.10 KG (Without Battery) 2.24 KG (with 4 cell battery) |
| 2nd Battery Weight (Kg) | 2.24 KG (% cell battery) (Optional) |
| Dimension (cm) | 39.0(W) x 26.6(D) x 2.35 ~ 2.35 (H) cm |
| AC Adapter | 180W AC Adapter Output : 19V DC, 9.5A, 180W Input : 100~240V AC, 50/60Hz universal |
| Battery | 64WHrs, 4S1P, 4-cell Li-ion Prismatic Battery pack |
| Keyboard type | Illuminated Chiclet Keyboard |
| Software | Gaming Center ROG Game First III ICEsound |
| Security | HDD User Password Protection and Security BIOS Booting User Password Protection |
| Supplied Accessories | Without carry bag |
FX502VM-DM120T (PHP 79,995)
| Part No | 90NB0DR5-M01830 |
| Model Name | FX502VM-DM120T |
| EAN Code | |
| UPC Code | |
| LCD Cover Color & Decoration | Black–Aluminum |
| Top Case Color & Decoration | Black–Plastic |
| On board processor | Intel® Core™ i7-6700HQ Processor 2.6 GHz (6M Cache, up to 3.5 GHz) |
| Operating System | Windows 10 (64bit) |
| Office | Includes 1 month Trial for New Microsoft Office 365 Customers |
| Chipset | Mobile Intel® HM170 Express Chipsets |
| Memory Slot | 1x |
| On board memory | DDR4 8GB |
| Memory Max. | 24G |
| DIMM Memory | DRAM DDR4 8G |
| Total System Memory | DDR4 8GB + DRAM DDR4 8G |
| Storage | SATA 1TB 7200RPM 2.5′ HDD SATA3 256G M.2 SSD |
| EMMC/ISSD | N/A |
| Display | 15.6’//LED Back-lit//Ultra Slim 200nits//FHD 1920×1080 16:9//AG//NTSC:45%//WVFILM 140 degrees |
| External video display modes | HDMI 1.4 |
| Discrete/Share | Discrete |
| Video Graphics | NVIDIA GeForce GTX1060 (N17E-G1) |
| IGPU | N/A |
| Video memory | GDDR5 3GB |
| Video Camera | HD web camera |
| FingerPrint | N/A |
| On board Wireless | N/A |
| Wireless(Module) | 802.11ac+Bluetooth 4.1 (Dual band) 2*2 |
| LAN | 10/100/1000 Mbps |
| Card Reader | Sepc: SD、MMC |
| USB Port | 3x USB 3.0 1x USB3.1 Type C (gen 2) |
| Interface | 1x Headphone-out & Audio-in Combo Jack 1x RJ45 LAN Jack for LAN insert 1x HDMI 1x mini Display Port 1x USB3.1-Type C(Gen2) with Thunderbolt |
| Audio | Built-in speaker Built-in array microphone Audio by ICEpower® Sonic Master |
| Weight (Kg) | 2.10 KG (Without Battery) 2.24 KG (with 4 cell battery) |
| 2nd Battery Weight (Kg) | 2.24 KG (% cell battery) (Optional) |
| Dimension (cm) | 39.0(W) x 26.6(D) x 2.35 ~ 2.35 (H) cm |
| AC Adapter | 180W AC Adapter Output : 19V DC, 9.5A, 180W Input : 100~240V AC, 50/60Hz universal |
| Battery | 64WHrs, 4S1P, 4-cell Li-ion Prismatic Battery pack |
| Keyboard type | Illuminated Chiclet Keyboard |
| Software | Gaming Center ROG Game First III ICEsound |
| Security | HDD User Password Protection and Security BIOS Booting User Password Protection |
| Supplied Accessories | Without carry bag |
WHERE TO BUY FX502
- Asus Concept Store, 3rd Floor, SM Cyberzone, SM Fairview
- Asus Concept Store, 2nd Floor, SM Cyberzone, SM Bacolod
- Asus Concept Store, 3rd Floor, SM Cyberzone, SM Lanang
- ROG Concept Store, 4th Floor, SM CyberZone, Megamall
- Asus Concept Store, 3rd Floor, SM Cyberzone, SM IloIlo
- Asus Concept Store, 3rd Floor, SM Festival Mall, Alabang
- Asus Concept Store, 2nd Floor, SM CyberZone, Mall of Asia
- ROG Concept Store, 4th Floor, SM CyberZone, North Edsa
- Asus Concept Store, 2nd Floor, SM Cyberzone, SM Cabanatuan
- Asus Concept Store, 3rd Floor, Ayala Centrio Mall, CDO
- Asus Concept Store, 2nd Floor, SM Cyberzone, SM Cebu
- Asus Concept Store, 4th Floor, SM CyberZone, Megamall
- Asus Concept Store, 4th Floor, SM CyberZone, North Edsa
